EK 520-SRXL-120 ORNGLITE X-RING [ONC01] #
The EK 520 SRXL chain is a high-performance motorcycle chain designed for both street and off-road use. It features a 520 pitch and is available in various lengths, like the 120-link version. The chain incorporates features like lightening holes and a Quadra X-Ring (QX-Ring) for reduced friction and extended lifespan compared to standard chains.
Features
- Pitch: 520
- Tensile Strength: 8,500 lbs
- Wear Life Index: 1500 (Standard is 100)
- Weight (per 100 links): 1.57kg
- Pin Diameter: 5.38mm
- Pin Length: 19.95mm
- Roller Diameter: 10.16mm
- Inner Plate Thickness: 2mm
- Outer Plate Thickness: 2mm
- Max Displacement (CCs): 750 (Street), 650 (Dirt)
- Seal Type: QX-Ring (Quadra X-Ring)
